转让瑞士二手普通精密车床SCHAUBLIN 150

2020-08-31 11:01 124 hits

Favorites

Manager

Report

Company：: 富氏网络有限公司

Authentication：

Service information

编号M21007中心车床;中心高:150 mm;中心距:600 mm;十字滑台上的回转直径:177 mm;床身上的回转直径:340 mm;轴孔:40 mm;主轴箱锥度 MK:5;主轴锥度;卡盘:D 1-4";主轴速度;无极变速; 从:55 rpm;高到:3000 rpm;尾座锥度:5 MT;主轴直径:60 mm;进给;数量(档位):48;长度; 从:0.015 mm/r;高到:0.35 mm/r;前端; 从:0.015 mm/r;高到:0.35 mm/r;电压 50HZ 3相 380伏;主轴电机:2.70 HP;总功率要求:6.30 HP;机器的重量大约:1250 kg;机器整体尺寸;长度:1730 mm;宽度:970 mm;高度:1300 mm;各种配件;3爪卡盘;冷却系统;三爪挡板折叠打开;快速换刀:MULTIFIX;整套刀柄;整套夹头;旋转中心;钻头夹盘;Lamp;钻削尾座

价格：面议成色：9成新以上

所在地：上海交易地点：全国各地

联系人：吴经理已实名 [ 商家 ]

手机： (归属地：陕西西安)

公司：西安有瑞莎机械设备有限责任公司已实名
